ALLIED TELESIS DESKTOP MINI MEDIA CONVERTER 100TX TO 1
Desktop Mini Media Converter 100TX to 100FX LC Connector USB Power Only
- Brand: ALLIED TELESIS
- Category: Network Accessories
- SKU: 4332516
- MPN: AT-DMC100/LC-00
ALLIED TELESIS
Allied Telesis AT-DMC100/LC-00 network media converter 100 Mbit/s…
- Our SKU
- MPN
- Barcode
- Rating
- No reviews yet
−23%
Overview
The Allied Telesis DMC100 Series of Fast Ethernet mini media converters are among the smallest media converters on the market today.
Overview
Just 1.25"W × 3.6"D × 0.85"H
Can be powered with the included Micro USB to USB cable and plugged directly into a laptop or desktop
Compact, with a very small carbon footprint
No installation time, just plug and play
Auto negotiation
Transparent to IEEE 802.1Q packets
Auto MDI/MDI-X
Smart MissingLink
Smart Link Restoration
Link test
RoHS compliant
Overview
Just 1.25"W × 3.6"D × 0.85"H
Can be powered with the included Micro USB to USB cable and plugged directly into a laptop or desktop
Compact, with a very small carbon footprint
No installation time, just plug and play
Auto negotiation
Transparent to IEEE 802.1Q packets
Auto MDI/MDI-X
Smart MissingLink
Smart Link Restoration
Link test
RoHS compliant
Key features
- Maximum data transfer rate: 100 Mbit/s
- Converter input interface: 100Base-TX
- Converter output interface: 100Base-FX
- Networking standards: IEEE 802.1Q
- Ethernet interface type: Fast Ethernet
- Fiber ethernet cabling technology: 100BASE-FX
- Data transfer rate: 100 Mbit/s
- Auto MDI/MDI-X: Yes
- Auto-negotiation: Yes
- Duplex system: Full, Half
- Link Loss Carry Forward (LLCF) supported: Yes
- Link Loss Return (LLR) supported: Yes
- Maximum transfer distance: 2000 m
- Wavelength: 1310 nm
- Fiber mode structure: Multi-mode
- Fiber cable diameters supported (core/cladding): 50/125,62.5/125 µm
- Tx power (min): -22.5 dBmW
- Tx power (max): -14 dBmW
- Rx power (min): -32 dBmW
- Internal: No
- LED indicators: Yes
- Product colour: Grey
- Connectivity technology: Wired
- Ethernet LAN (RJ-45) ports: 1
Specifications
Power
| Input voltage | 5 V |
|---|---|
| Input current | 0.5 A |
Network
| Maximum data transfer rate | 100 Mbit/s |
|---|---|
| Converter input interface | 100Base-TX |
| Converter output interface | 100Base-FX |
| Networking standards | IEEE 802.1Q |
| Ethernet interface type | Fast Ethernet |
| Fiber ethernet cabling technology | 100BASE-FX |
| Data transfer rate | 100 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Duplex system | Full, Half |
| Link Loss Carry Forward (LLCF) supported | Yes |
| Link Loss Return (LLR) supported | Yes |
Features
| Internal | No |
|---|---|
| LED indicators | Yes |
| Product colour | Grey |
Performance
| Maximum transfer distance | 2000 m |
|---|---|
| Wavelength | 1310 nm |
| Fiber mode structure | Multi-mode |
| Fiber cable diameters supported (core/cladding) | 50/125,62.5/125 µm |
| Tx power (min) | -22.5 dBmW |
| Tx power (max) | -14 dBmW |
| Rx power (min) | -32 dBmW |
Certificates
| Compliance certificates | RoHS |
|---|---|
| Safety | UL60950-1, EN60950-1 |
| Certification | FCC Class A, CISPR 22 Class A, EN55022 Class A, C-TICK, VCCI Class A |
Ports & interfaces
| Connectivity technology | Wired |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | LC |
Weight & dimensions
| Width | 31.8 mm |
|---|---|
| Depth | 91.4 mm |
| Height | 21.6 mm |
| Weight | 113.4 g |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -15 - 65 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
Questions
$500.24inc GST
