Alta Labs S24-POE 24-Port Managed Enterprise PoE Switch 2x 10GigE SFP+ 16x PoE+ Ports 240W PoE Power Budget
24-Port Managed Enterprise PoE Switch 2x 10GigE SFP+ 16x PoE+ Ports 240W PoE Power Budget
- Brand: Alta Labs
- Category: Switches
- SKU: S24-POE
- MPN: S24-POE
Alta LabsAlta Labs S24-POE 24-Port Managed Enterprise PoE Switch 2x 10GigE SFP+ 16x PoE+ Ports 240W PoE Power Budget
- Warranty
- 24 months
Overview
24-Port Managed Enterprise PoE Switch 2x 10GigE SFP+ 16x PoE+ Ports 240W PoE Power Budget
Specifications
SFP
| SFP | Blue: Link/Activity (1, 2.5, or 5 Gbps); White: Link/Activity (10 Gbps |
|---|
Output
| Output | PoE+, 54VDC, 0.6A Max. |
|---|
Network
| Network | Orange: 10/100 Mbps, Blue: 1000 Mbps |
|---|
Mounting
| Mounting | Rackmount, Wallmount |
|---|
Dimensions
| Dimensions | 44 x 254 x 441.5 mm |
|---|
EMI Rating
| EMI Rating | EMI Class-A with 3dB margin |
|---|
Management
| Management | Factory reset button |
|---|
PoE Supply
| PoE Supply | 30 Watts per port |
|---|
Per Port PoE
| Per Port PoE | (16) 802.3at PoE+ |
|---|
Power Supply
| Power Supply | Universal AC, 100 - 240VAC 50-60Hz Internal |
|---|
Certifications
| Certifications | CE, FCC, IC |
|---|
Interface Ports
| Interface Ports | (24) 10/100/1000 Mbps |
|---|
Material Finish
| Material Finish | Powder coat - Matte |
|---|
Operating Humidity
| Operating Humidity | 10 to 90% Noncondensing |
|---|
Switching Capacity
| Switching Capacity | 88 Gbps |
|---|
Operating Temperature
| Operating Temperature | -5 to 50° C (23 to 122° F) |
|---|
Idle Power Consumption
| Idle Power Consumption | 15 Watts |
|---|
Non-blocking Throughput
| Non-blocking Throughput | 44 Gbps |
|---|
Energy-Efficient Ethernet
| Energy-Efficient Ethernet | Yes |
|---|
RJ45 Port Surge Protection
| RJ45 Port Surge Protection | 12kV for ESD - contact, 25kV for ESD - Air |
|---|
Max Power Consumption w/o PoE
| Max Power Consumption w/o PoE | 53 Watts |
|---|
Max Power Consumption Full PoE
| Max Power Consumption Full PoE | 295 Watts |
|---|
$1,026.94inc GST
