Aruba 40G QSFP+ MPO eSR4 300M XCVR HPE
HPE Aruba Networking 40G QSFP+ MPO eSR4 300M Transceiver
- Brand: ARUBA
- Category: Switches
- SKU: 5706756
- MPN: R9F98A
ARUBAAruba 40G QSFP+ MPO eSR4 300M XCVR HPE
Overview
HPE Aruba Networking 40G QSFP+ MPO eSR4 300M Transceiver
Specifications
Power
| Power | +3.3V single power supply |
|---|
Connector
| Connector | MTP/MPO-12 (UPC) |
|---|
Compliance
| Compliance | IEEE 802.3ba, CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, INF-8438i, QSFP+ MSA, RoHS, SFF-8436 |
|---|
Media Type
| Media Type | Multi-Mode Fiber (MMF) -OM3/OM4/OM5 |
|---|
Modulation
| Modulation | NRZ (Non-Return to Zero) |
|---|
Receiver Type
| Receiver Type | PIN photodiode |
|---|
Transmitter Type
| Transmitter Type | VSCEL Laser |
|---|
Relative Humidity
| Relative Humidity | 5 to 85% |
|---|
Temperature Range
| Temperature Range | Standard 0°-70°C |
|---|
Tx Wave Bandwidth
| Tx Wave Bandwidth | 20 nm (840-860 nm) |
|---|
Average Link Budget
| Average Link Budget | 2.5 dB |
|---|
SDH/SONET Standards
| SDH/SONET Standards | STM-256 (39.81 Gbps) |
|---|
Storage Temperature
| Storage Temperature | -40° to 85°C |
|---|
Supported Data Rate
| Supported Data Rate | 44.8 Gbps |
|---|
Supported Ethernet Applications
| Supported Ethernet Applications | 40G Ethernet (41.25Gbps) |
|---|
Average Launch Power (Max) Each Lane
| Average Launch Power (Max) Each Lane | 1 dBm |
|---|
Average Launch Power (Min) Each Lane
| Average Launch Power (Min) Each Lane | -7 dBm |
|---|
Average Receiver Sensitivity (Max) Each Lane
| Average Receiver Sensitivity (Max) Each Lane | 2.4 dBm |
|---|
Average Receiver Sensitivity (Min) Each Lane
| Average Receiver Sensitivity (Min) Each Lane | -9.5 dBm |
|---|
Optical Transport Network (OTN) Applications
| Optical Transport Network (OTN) Applications | OTU3 (43.01Gbps), OTU3e2 (44.58Gbps) |
|---|
$6,527.39inc GST
