| USB | 1 x USB 20Gbps connector (supports USB Type-C), 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports |
|---|
| Miscellaneous | 3 x Addressable Gen 2 headers, 1 x Alteration PCIe mode switch, 1 x Chassis Intrusion header, 1 x CPU Over voltage jumper, 1 x Front Panel Audio header (F_AUDIO), 1 x Start button, 1 x 10-1 pin System Panel header, 1 x Thermal Sensor header |
|---|
| Power Related | 1 x 24-pin Main Power connector, 2 x 8-pin +12V CPU Power connectors |
|---|
| Audio Features | SupremeFX Shielding Technology, Savitech SV3H712 AMP, Rear optical S/PDIF out port, Premium audio capacitors, Audio cover |
|---|
| Storage Related | 4 x M.2 slots (Key M), 2 x SATA 6Gb/s ports |
|---|
| AMD X870 Chipset | 1 x PCIe 4.0 x16 slot (supports x4 mode) |
|---|
| Fan and Cooling Related | 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump header, 5 x 4-pin Chassis Fan headers |
|---|
| Front USB (Total 9 ports) | 1 x USB 20Gbps connector (supports USB Type-C), 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports, 2 x USB 2.0 headers support 4 additional USB 2.0 ports |
|---|
