ATEN USB DUAL VGA CAT 5 KVM EXTENDER

Networking > Network Accessories

  • Brand: ATEN
  • Category: Networking
  • SKU: CE775-AT-U
  • MPN: CE775-AT-U
ATEN

ATEN CE775 AV extender AV transmitter & receiver Black

SKU
CNZ-DD-011344
MPN
CE775-AT-U

Overview

ATEN CE775 Dual View KVM Extenders with Deskew function allows access to a computer system from a remote Dual View console up to 300 m away. The dual view function provides support for two displays, allowing the video output to seamlessly display on two monitors. Its advanced PC Wake - Up feature that allows you simply uses a pushbutton from the remote dual view console to wake a PC at the local site via RS-232, no need to go to the local site to wake up the PC. It eliminates the need for traveling back and forth between the local computer and remote console, effi cient and flexible.

Use the improved built-in front panel tuners to easily adjust the picture quality. In addition, you can automatically synchronize the time delay of RGB signals in order to compensate for distance, easy and fast than ever.

Key features

  • Type: AV transmitter & receiver
  • Maximum resolution: 1920 x 1200 pixels
  • Cable types supported: Cat5e
  • Maximum transfer distance: 300 m
  • Audio system: Multichannel
  • LED indicators: Yes
  • Product colour: Black
  • RJ-45 input ports: 2
  • RJ-45 output ports: 2
  • VGA (D-Sub) input ports: 4
  • Audio input: 3.5mm
  • Audio output: 3.5mm
  • DC-in jack: Yes
  • Operating voltage: 5.3 V
  • External power adapter: Yes
  • Operating temperature (T-T): 0 - 50 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 80%
  • Dimensions (WxDxH): 75.8 x 200 x 42 mm
  • Weight: 690 g
  • Connector type: USB, SPHD-17, RS-232

Specifications

Power

Operating voltage5.3 V
External power adapterYes

Features

TypeAV transmitter & receiver
Maximum resolution1920 x 1200 pixels
Cable types supportedCat5e
Maximum transfer distance300 m
Audio systemMultichannel
LED indicatorsYes
Product colourBlack

Technical details

Connector typeUSB, SPHD-17, RS-232

Ports & interfaces

RJ-45 input ports2
RJ-45 output ports2
VGA (D-Sub) input ports4
Audio input3.5mm
Audio output3.5mm
DC-in jackYes

Weight & dimensions

Dimensions (WxDxH)75.8 x 200 x 42 mm
Weight690 g

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Questions

$2,405.79inc GST
