APC Back-UPS PRO Line-Interactive 1600VA (960W) with AVR, 230V
- Brand: APC
- Category: Uninterruptible Power Supplies (upss)
- SKU: BR1600SI
- MPN: BR1600SI
APC
APC Back-UPS Pro, 1600VA/960W, Tower, 230V, 8x IEC C13 outlets, Sine…
- SKU
- CNZ-CD-004488
- MPN
- BR1600SI
- Rating
- No reviews yet
−7%
Overview
APC Back-UPS PRO Line-Interactive 1600VA (960W) with AVR, 230V Input/Output. 8x IEC C14 Outlets. With Battery Backup & Surge Protect. USB Port charging ports, Sinewave Power & LCD Display.
Key features
- UPS topology: Line-Interactive
- Output power capacity: 1.6 kVA
- Output power: 960 W
- Waveform: Sine
- Input operation voltage (min): 176 V
- Input operation voltage (max): 294 V
- Input frequency: 50/60 Hz
- Output operation voltage (max): 230 V
- Output frequency: 50/60 Hz
- Automatic Voltage Regulation (AVR): Yes
- Maximum current: 10 A
- Surge energy rating: 509 J
- Noise level: 45 dB
- Power protection features: Overload
- Audible alarm(s): Yes
- Audible alarm modes: Alarm when on battery, Low battery alarm, Overload alarm
- AC outlet types: C13 coupler
- Power plug: C14 coupler
- AC outlets quantity: 8 AC outlet(s)
- USB port: Yes
- USB 2.0 ports quantity: 2
- Ethernet LAN (RJ-45) ports: 1
- SmartSlot: No
- SmartConnect port: No
Specifications
Spec
| Spec | Output |
|---|
Color
| Color | Black |
|---|
Runtime
| Runtime | View Runtime Graph (Available in Technical Tab on site) View Runtime Chart (Available in Technical Tab on site) |
|---|
Topology
| Topology | Line interactive |
|---|
Approvals
| Approvals | A-Tick, C-Tick, CE, EAC, GS Mark, RCM, TISI |
|---|
Filtering
| Filtering | Full time multi-pole noise filtering : 10% of IEEE surge let-through : zero clamping response time: instantaneous |
|---|
SCC Codes
| SCC Codes | 10731304346927 |
|---|
Net Weight
| Net Weight | 12.1KG |
|---|
Battery type
| Battery type | Lead-acid battery |
|---|
RBC Quantity
| RBC Quantity | 1 |
|---|
Runtime (20)
| Runtime (20) | Disclaimer: Documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user's applications. |
|---|
Runtime (21)
| Runtime (21) | Communications & Management |
|---|
Audible Alarm
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
|---|
Control panel
| Control panel | Multifunction LCD status and control console |
|---|
Maximum Depth
| Maximum Depth | 368MM, 36.8CM |
|---|
Maximum Width
| Maximum Width | 100MM, 10.0CM |
|---|
Filtering (29)
| Filtering (29) | Physical |
|---|
Maximum Height
| Maximum Height | 260MM, 26.0CM |
|---|
SCC Codes (43)
| SCC Codes (43) | Environmental |
|---|
Shipping Depth
| Shipping Depth | 482MM, 48.2CM |
|---|
Shipping Width
| Shipping Width | 223MM, 22.3CM |
|---|
Input frequency
| Input frequency | 50/60 Hz +/- 3 Hz Auto-sensing |
|---|
Shipping Height
| Shipping Height | 359MM, 35.9CM |
|---|
Shipping weight
| Shipping weight | 13.75KG |
|---|
Input Connections
| Input Connections | IEC 60320 C14 |
|---|
Interface Port(s)
| Interface Port(s) | USB |
|---|
Standard warranty
| Standard warranty | 2 years repair or replace, 3 years repair or replace for European Union countries |
|---|
Storage Elevation
| Storage Elevation | 0 - 15240meters |
|---|
Audible Alarm (25)
| Audible Alarm (25) | Surge Protection and Filtering |
|---|
Output Connections
| Output Connections | (6) IEC 60320 C13(2) IEC 60320 C13 |
|---|
Master Carton Units
| Master Carton Units | 1.0 |
|---|
Operating Elevation
| Operating Elevation | 0 - 3048meters |
|---|
Storage Temperature
| Storage Temperature | -15 - 45 °C |
|---|
Surge energy rating
| Surge energy rating | 509Joules |
|---|
Data Line Protection
| Data Line Protection | RJ45 10/100/1000 Base-T Ethernet protection |
|---|
Master Carton Weight
| Master Carton Weight | 14.61 |
|---|
Maximum Input Current
| Maximum Input Current | 10.0A |
|---|
Nominal Input Voltage
| Nominal Input Voltage | 230V |
|---|
Operating Temperature
| Operating Temperature | 0 - 40 °C |
|---|
Output power capacity
| Output power capacity | 960 Watts / 1.6kVA |
|---|
Typical recharge time
| Typical recharge time | 16hour(s) |
|---|
Nominal Output Voltage
| Nominal Output Voltage | 230V |
|---|
Output Connections (7)
| Output Connections (7) | Input |
|---|
Standard warranty (57)
| Standard warranty (57) | Sustainable Offer Status |
|---|
Standard warranty (58)
| Standard warranty (58) | RoHS: Compliant |
|---|
Storage Elevation (49)
| Storage Elevation (49) | Disclaimer: Documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user's applications. |
|---|
Storage Elevation (50)
| Storage Elevation (50) | Environmental |
|---|
Storage Elevation (51)
| Storage Elevation (51) | Audible noise at 1 meter from surface of 45.0dBAunit |
|---|
Storage Elevation (52)
| Storage Elevation (52) | Online thermal dissipation 20.0BTU/hr |
|---|
Storage Elevation (53)
| Storage Elevation (53) | Conformance |
|---|
Maximum Input Current (13)
| Maximum Input Current (13) | Batteries & Runtime |
|---|
Equipment protection policy
| Equipment protection policy | Lifetime : 150000 euros, Lifetime : 200000 AUD, Lifetime : 75000 GBP |
|---|
Operating Relative Humidity
| Operating Relative Humidity | 0 - 95 (Non-condensing) % |
|---|
Battery Charge Power (Watts)
| Battery Charge Power (Watts) | 16 Watts |
|---|
Expected Battery Life (years)
| Expected Battery Life (years) | 3 - 5 |
|---|
Max Configurable Power (Watts)
| Max Configurable Power (Watts) | 960 Watts / 1.6kVA |
|---|
Output Frequency (sync to mains)
| Output Frequency (sync to mains) | 50/60 Hz +/- 1 Hz Sync to mains |
|---|
Input voltage range for main operations
| Input voltage range for main operations | 176 - 294V |
|---|
Master Carton Dimensions (Length x Width x Height)
| Master Carton Dimensions (Length x Width x Height) | 381 x 483 x 229MM |
|---|
Questions
$1,060.29inc GST
