POWERSHIELD Centurion RT 1000VA/ 900W Double Conversion True Online
- Brand: Powershield
- SKU: PSCERT1000
- MPN: PSCERT1000
Powershield
POWERSHIELD Centurion RT 1000VA/ 900W Double Conversion True Online
- SKU
- CNZ-CD-004549
- MPN
- PSCERT1000
- Rating
- No reviews yet
−28%
Overview
POWERSHIELD Centurion RT 1000VA/ 900W Double Conversion True Online UPS. Power Factor 0.9 Rack/Tower Design (2RU) Hot-Swappable Battery. EBM Compatible to Extend Runtime.
Specifications
EMC
| EMC | EN62040-2 2006 |
|---|
RoHS
| RoHS | Directive 2011/65/EU |
|---|
Spec
| Spec | INPUT |
|---|
Phase
| Phase | Single phase with ground |
|---|
OUTPUT
| OUTPUT | Output Power Factor: 0.9 |
|---|
Safety
| Safety | EN62040-1-1 2003, IEC60950-1-1 |
|---|
Weight
| Weight | 18kg |
|---|
Humidity
| Humidity | 20 - 90% (RH Non-condensing) |
|---|
Software
| Software | PowerShield NetGuard® software - supports Windows based operating systems, Linux, Unix and Mac |
|---|
Interface
| Interface | USB or RS232 as standard, Intelligent slotfor PSSNMP, PSModbus or PSAS400 dry contact |
|---|
Noise Level
| Noise Level | < 50dBA @ 1 Meter |
|---|
Temperature
| Temperature | 0 - 40°C |
|---|
Weight (32)
| Weight (32) | OPERATING ENVIRONMENT |
|---|
Battery Mode
| Battery Mode | 86% |
|---|
Audible Alarm
| Audible Alarm | Battery Mode, Bypass Mode, Low Battery (Batt. Mode),Fault, Overload |
|---|
Transfer Time
| Transfer Time | 4ms (Typical) |
|---|
Frequency Range
| Frequency Range | 40Hz - 70Hz |
|---|
Full Protection
| Full Protection | Overload, discharge, thermal, short circuit and overcharge protection |
|---|
Noise Level (36)
| Noise Level (36) | COMPLIANCE |
|---|
Surge Protection
| Surge Protection | 984 Joules / 22000 Amps |
|---|
Battery Mode (17)
| Battery Mode (17) | BATTERY |
|---|
LCD Display/Alarm
| LCD Display/Alarm | UPS Status, Load & Battery Level, Input/Output Voltage, Batt. Time Remaining and Fault Indicators |
|---|
Audible Alarm (29)
| Audible Alarm (29) | PHYSICAL |
|---|
Transfer Time (14)
| Transfer Time (14) | EFFICIENCY |
|---|
Current Crest Ratio
| Current Crest Ratio | 5:1 (max.) |
|---|
ECO Mode (Advanced)
| ECO Mode (Advanced) | 98% |
|---|
Battery Type & Number
| Battery Type & Number | 12 V*9AH (x3) |
|---|
Dimension (D x W x H)
| Dimension (D x W x H) | 480 x 438 x 88 mm |
|---|
Surge Protection (24)
| Surge Protection (24) | COMMUNICATIONS & MANAGEMENT |
|---|
Typical Recharge Time
| Typical Recharge Time | 4 hours recover to 90% capacity |
|---|
Charging Current (max.)
| Charging Current (max.) | Standard Model -1.5Amp, Long Run Model - 1Amp/2Amp /4Amp/6Amp (factory default is 6Amp) |
|---|
Power Factor Correction
| Power Factor Correction | >0.99 @ nominal voltage (100% load) |
|---|
Output Voltage (AC Mode)
| Output Voltage (AC Mode) | 240Vac (Selectable 208/220/230/240Vac) |
|---|
Charging Current (max.) (21)
| Charging Current (max.) (21) | PROTECTION |
|---|
Frequency Range (Batt. Mode)
| Frequency Range (Batt. Mode) | 50Hz or 60Hz ±1Hz |
|---|
Voltage Regulation (Bat. Mode)
| Voltage Regulation (Bat. Mode) | ±1% |
|---|
Voltage Range - Low Line Comeback
| Voltage Range - Low Line Comeback | 170Vac / 150Vac / 130Vac / 120Vac ± 5% |
|---|
Voltage Range - Low Line Transfer
| Voltage Range - Low Line Transfer | 160Vac / 140Vac / 120Vac / 110Vac ± 5% (based on load percentage 100% - 80% /80% - 70% / 70% - 60% / 60% - 0) |
|---|
Voltage Range - High Line Comeback
| Voltage Range - High Line Comeback | 290Vac ± 5% |
|---|
Voltage Range - High Line Transfer
| Voltage Range - High Line Transfer | 300Vac ± 5% |
|---|
Questions
$1,417.94inc GST
