D-LINK DGS-1016S Switch

  • Brand: D-Link
  • Category: Switches
  • SKU: DLDGS1016S
  • MPN: DGS-1016S
D-Link

D-Link DGS-1016S Unmanaged Gigabit Ethernet (10/100/1000) Black

SKU
CNZ-DS-001241
MPN
DGS-1016S

Overview

Slim, Low-Profile Design
Allowing the switch to be placed on the desktop or mounted on the wall

High-Speed Gigabit Networking
Connect up to 16 devices for fast file transfers and smooth media streaming

Silent Operation
Fanless design means the switch is virtually silent when in use

Energy Efficient
Integrated energy-saving technology to reduce power usage automatically

Connect More, Connect Faster
The 16-Port Gigabit Unmanaged Switch is ideal for homes and small-to-medium-sized businesses looking for a quick and easy way to upgrade or expand their network. Its slim, low-profile design means it can be placed on the desktop or mounted on the wall. Simple to set up with no software or configuration needed.

Silent and built to last
Metal casing with a fanless design not only means silent operation but also reduces energy usage and enhances reliability.

Visual Cable Diagnostics
LEDs on each port allow you to quickly see when something is wrong with the connection.

Good for your wallet, great for the planet
With its integrated power-saving technologies, the switch automatically reduces power consumption when a low-traffic or idle port is detected. It can also detect when a shorter network cable is connected to use less power on that port.

Key features

  • Switch type: Unmanaged
  • Quality of Service (QoS) support: Yes
  • Basic switching RJ-45 Ethernet ports quantity: 16
  • Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
  • Networking standards: IEEE 802.1p, IEEE 802.3az, IEEE 802.3x
  • 10G support: No
  • Copper ethernet cabling technology: 1000BASE-T
  • Full duplex: Yes
  • Half duplex: Yes
  • Flow control support: Yes
  • Auto MDI/MDI-X: Yes
  • Auto-negotiation: Yes
  • Cable length detection: Yes
  • Switching capacity: 32 Gbit/s
  • MAC address table: 8000 entries
  • Store-and-forward: Yes
  • Number of queues: 8
  • Jumbo frames support: Yes
  • Jumbo frames: 9216
  • Packet forwarding rate (1 Gbps): 1488000 pps
  • Packet forwarding rate (100 Mbps): 148800 pps
  • Packet forwarding rate (10 Mbps): 14880 pps
  • Packet buffer memory: 0.512 MB
  • Product colour: Black

Specifications

Power

DC input voltage12 V
Input current1 A
Power consumption (max)8.89 W

Design

Product colourBlack
LED indicatorsActivity, Link, Power, Speed

Network

Networking standardsIEEE 802.1p, IEEE 802.3az, IEEE 802.3x
10G supportNo
Copper ethernet cabling technology1000BASE-T
Full duplexYes
Half duplexYes
Flow control supportYes
Auto MDI/MDI-XYes
Auto-negotiationYes
Cable length detectionYes

Performance

FanlessYes
Mean time between failures (MTBF)564658 h

Certificates

CertificationCE, FCC, ICES 003, RCM

Data transmission

Switching capacity32 Gbit/s
MAC address table8000 entries
Store-and-forwardYes
Number of queues8
Jumbo frames supportYes
Jumbo frames9216
Packet forwarding rate (1 Gbps)1488000 pps
Packet forwarding rate (100 Mbps)148800 pps
Packet forwarding rate (10 Mbps)14880 pps
Packet buffer memory0.512 MB

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)

Management features

Switch typeUnmanaged
Quality of Service (QoS) supportYes

Weight & dimensions

Width280 mm
Depth110 mm
Height25 mm
Weight770 g

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 95%
Heat dissipation30.32 BTU/h

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Questions

$166.74inc GST
