DELL Pro 16 Plus PB16250 Intel Core Ultra 7 268V Laptop 40.6 cm…

SKU: CNZ-IM-041919
MPN: CTO735_PB16250_NZ
Rating: No reviews yet

DELL PRO 16PLUS U7 268V32GB512GBW11P3YPS — DELL

Overview

DELL Pro 16 Plus PB16250. Product type: Laptop, Form factor: Clamshell. Processor family: Intel Core Ultra 7, Processor model: 268V. Display diagonal: 40.6 cm (16"), HD type: Full HD+, Display resolution: 1920 x 1200 pixels. Internal memory: 32 GB, Internal memory type: LPDDR5x-SDRAM. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel Arc Graphics 140V. Operating system installed: Windows 11 Pro. Product colour: Aluminium. Weight: 1.84 kg

Key features

Product type: Laptop
Product colour: Aluminium
Form factor: Clamshell
Housing material: Aluminium
Display diagonal: 40.6 cm (16")
Display resolution: 1920 x 1200 pixels
Touchscreen: No
HD type: Full HD+
Panel type: IPS
Native aspect ratio: 16:10
Anti-glare screen: Yes
Display brightness: 300 cd/m²
Pixel density: 142 ppi
RGB colour space: NTSC
Colour gamut: 45%
Maximum refresh rate: 60 Hz
Contrast ratio (typical): 1000:1
Processor manufacturer: Intel
Processor family: Intel Core Ultra 7
Processor generation: Intel Core Ultra (Series 2)
Processor model: 268V
Processor cores: 8
Processor threads: 8
Processor boost frequency: 5 GHz

At a glance

Audio chip	Cirrus Logic CS42L43
Number of built-in speakers	2
Speaker power	2.5 W
Built-in microphone	Yes
Number of microphones	2
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V

All 136 specifications

Specifications

Audio

Audio chip	Cirrus Logic CS42L43
Number of built-in speakers	2
Speaker power	2.5 W
Built-in microphone	Yes
Number of microphones	2

Power

AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Yes
USB Type-C required charging power (min)	27 W
USB Type-C required charging power (max)	72 W
USB Power Delivery (USB PD)	Yes
USB charging voltage	5,9,15,20 V

Camera

Front camera	Yes
Front camera resolution (numeric)	2.07 MP
Front camera resolution	1920 x 1080 pixels
Front camera HD type	Full HD
Video capturing speed	30 fps
Infrared (IR) camera	Yes

Design

Product type	Laptop
Product colour	Aluminium
Form factor	Clamshell
Housing material	Aluminium

Memory

Internal memory	32 GB
Internal memory type	LPDDR5x-SDRAM
Memory form factor	On-board
Maximum internal memory	32 GB
Memory data transfer rate	8533 MT/s

Battery

Number of battery cells	3
Battery capacity	55 Wh
Battery voltage	11.7 V
Fast charging	Yes
Battery charge indicator	Yes
Battery weight	220 g

Display

Display diagonal	40.6 cm (16")
Display resolution	1920 x 1200 pixels
Touchscreen	No
HD type	Full HD+
Panel type	IPS
Native aspect ratio	16:10
Anti-glare screen	Yes
Display brightness	300 cd/m²
Pixel density	142 ppi
RGB colour space	NTSC
Colour gamut	45%
Maximum refresh rate	60 Hz
Contrast ratio (typical)	1000:1

Network

Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Mobile network connection	No
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi data rate (max)	5760 Mbit/s
Antenna type	2x2
WLAN controller model	Intel Wi-Fi 7 BE201
WLAN controller manufacturer	Intel
Bluetooth	Yes

Storage

Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	PCI Express 4.0
NVMe	Yes
SSD form factor	M.2
Optical drive type	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)

Graphics

Discrete graphics card model	Not available
On-board graphics card	Yes
On-board GPU manufacturer	Intel
Discrete graphics card	No
On-board graphics card family	Intel Arc Graphics
On-board graphics card model	Intel Arc Graphics 140V

Keyboard

Pointing device	Touchpad
Numeric keypad	Yes
Keyboard backlit	Yes
Keyboard language	US English
Copilot key	Yes

Security

Cable lock slot	Yes
Cable lock slot type	Wedge
Face recognition	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Software

Operating system architecture	64-bit
Operating system installed	Windows 11 Pro

Processor

Processor manufacturer	Intel
Processor family	Intel Core Ultra 7
Processor generation	Intel Core Ultra (Series 2)
Processor model	268V
Processor cores	8
Processor threads	8
Processor boost frequency	5 GHz
Performance cores	4
Low Power Efficient-cores	4
Performance-core Max Turbo Frequency	5 GHz
Low Power Efficient-core Max Turbo Frequency	3.7 GHz
Performance-core base frequency	2.2 GHz
Low Power Efficient-core Base Frequency	2200 MHz
Processor cache	12 MB
Processor cache type	Smart Cache
Processor socket	BGA 2833
Processor base power	17 W
Maximum turbo power	37 W

Packaging content

AC adapter included	Yes

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
HDMI ports quantity	1
HDMI version	2.1
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes
PowerShare	Yes
Number of USB ports with PowerShare support	1

Weight & dimensions

Width	358 mm
Depth	251.4 mm
Height	21.4 mm
Height (front)	1.99 cm
Height (rear)	2.06 cm
Weight	1.84 kg

Operational conditions

Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	-15.2 - 3048 m
Non-operating altitude	-15.2 - 10668 m
Operating shock	110 G
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating vibration	1.3 G

Neural processor unit (NPU)

Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to	118 TOPs
NPU performance up to	48 TOPs
GPU performance up to	66 TOPs

Questions

$4,835.74inc GST
