On-line double conversion with Power Factor Correction (PFC) system
Approvals
Approvals
CE /CB report (TUV) / cULus / EAC / RCM / KC / Energy Star
Frequency
Frequency
50/60 Hz autoselection
Connection
Connection
1 x IEC-320-C20
EMC Markings
EMC Markings
IEC/EN 62040 -2 , FCC Class B, CISPR22 Class B
Audible Noise
Audible Noise
40dB
Configuration
Configuration
Rack/Tower
Frequency Range
Frequency Range
40-70 Hz
Nominal Voltage
Nominal Voltage
200/208/220/230/240V
Safety Markings
Safety Markings
IEC/EN 62040-1, UL 1778, CSA 22.3
Rating (VA/Watts)
Rating (VA/Watts)
2200/2200
Battery Management
Battery Management
ABM & Temperature compensated charging method (user selectable), Automatic battery test, deep discharge protection, automatic recognition of external battery units
Output Receptacles
Output Receptacles
8x IEC-320-C13, 2x IEC-320-C19
Communication Ports
Communication Ports
1 USB port + 1 serial RS232 port + 1 mini-terminal block for remote ON/OFF + 1 mini-terminal block for Remote Power Off + 1 mini-terminal block for Output relay
Input Voltage Range
Input Voltage Range
176-276V without derating (up to 100-276V with derating)
Operating Temperature
Operating Temperature
0 to 40C
Dimensions (H x W x D)
Dimensions (H x W x D)
130mm x 440mm x 485mm
Communications Card Slots
Communications Card Slots
1 slot for Network-MS card, ModBus-MS or Relay-MS cards
