| Additional info | Video Compression H.264 High Profile / Main Profile / Base Profile, Motion JPEG Image Sensor Resolution 1/2.7", 2 Megapixel, 1920H x 1080V Lens Type 1/2", F2.5, FOV: 180°(W) x 150°(H) Day & Night White LEDs with smart brightness control Max Video Resolution 1920x1080 Max Frame Rate 30 frames per second Wide Dynamic Range Yes, up to 120db Video Bit Rates 128 Kbps to 4 Mbps, multi-rate for preview & recording Embedded Analytics Motion detection (up to 4 privacy masks) Snapshots Triggered upon events, sent via email and/or FTP Multi-Stream Resolution High-performance streaming server allowing multiple simultaneous access Primary video stream: 1920 x 1080 resolution for continuous full HD recording Secondary video stream: 1280 x 720 resolution for SIP/VoIP video calls Third video stream: 320 x 240 resolution for smartphone applications Network Protocol TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS local upload and mass provisioning using TR-069 (pending), ARP/RARP, ICMP, LLDP-MED, DNS, DHCP, SSH, SMTP, TFTP, NTP, STUN, TLS, SRTP SIP/VoIP Support Broad interoperability with most 3rd party SIP/VoIP devices and leading SIP/NGN/IMS platforms Voice Codecs G.711µ /a-law, G.722, DTMF (RFC2833, SIP INFO), AEC QoS Layer 2 QoS (802.1Q, 802.1P) and Layer 3 QoS (ToS, DiffServ, MPLS) Security User and administrator level access control (pending), MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1Q Upgrade/ Provisioning Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 (Pending) or AES encrypted XML configuration file Audio Input Built-in microphone, up to 1.5m with AEC Audio Output Built-in HD loudspeaker (2 watts), sound quality suitable for up to 3 m Button 12-key touchpad plus a capacitive doorbell button, each with individual LED illumination RFID 125KHz: EM4100 (1 RFID card and 1 RFID key fob included) RFID Number Supported Up to 2,000 recommended Alarm Input Yes, 2 channels, Vin < 15V, for door sensor or other devices Alarm Output Yes, 2 channels, 125VAC/0.5A, 30VDC/2A, Normal Open or Normal Close, for electric lock, light switch or other devices Network Interface 10M/100M auto-sensing Expansion Interface RS485, Wiegand (26 bits) input and output Power Supply PoE IEEE 802.3af Class 3, or 12VDC/1A connection (AC power adapter not included) Interoperability ONVIF (Profile S) Ingress Protection Weather proof, vandal resistant, with support for extra back reinforcing metal plate Temperature and Humidity Operation: -30°C to 60°C (-22°F to 140°F) Storage: -35°C to 60°C (-31°F to 140°F) Humidity: 10% to 90% Non-condensing Protection Class IP66 (EN60529), IK09 (IEC62262) Compliance FCC: Part 15 subpart B Class B Part 15 C MPE CE: EN 55032 Class B EN 61000-3-2 EN 61000-3-3 EN 50130 EN 60950-1 EN 300330 EN 301489 EN 62311 RCM: AS/NZS CISPR 22 AS/NZS 4268 AS/NZS 60950.1 IC: ICES-003 RSS310 |
|---|
