LENKENG HDMI & IR Extender Kit Over Cat6/6A. 1080p up to 70m. HDMI & IR Extender Kit Over Cat6/6A 1080p up to 70m Supports EDID & IR Passback.
Brand: Lenkeng Category: Audio & Video SKU: LKV372P MPN: LKV372P Home Audio & Video Lenkeng Lenkeng LENKENG HDMI & IR Extender Kit Over Cat6/6A. 1080p up to 70m. Overview Specifications Questions Overview LENKENG HDMI & IR Extender Kit Over Cat6/6A. 1080p up to 70m. Supports EDID & IR Passback. Support PoC network cable power supply, only TX power supply is needed. Not Recommended for Cat5/5e
At a glance Body Properties - Weight TX:127g Body Properties - Dimension 75.0(L) x 60.0(W) x 16.5(H) mm Power Supply - Voltage/Current DC 5V/2A Power Supply - Power consumption TX+RX Transmission Distance - Cat6/6A/7 1080p@60Hz transmission 70 metres 4K@30Hz transmission 40 metres 1a Contact discharge level 2 (±4KV) 1b Air discharge level 3 (±8KV) HDMI Performance and Interface - HDR Support Operating Environment - Storage temperature -30°C~70°C Operating Environment - Working temperature -20°C~60°C
All 16 specifications Specifications Body Properties - Weight Body Properties - Weight TX:127g
Body Properties - Dimension Body Properties - Dimension 75.0(L) x 60.0(W) x 16.5(H) mm
Power Supply - Voltage/Current Power Supply - Voltage/Current DC 5V/2A
Power Supply - Power consumption Power Supply - Power consumption TX+RX
Transmission Distance - Cat6/6A/7 Transmission Distance - Cat6/6A/7 1080p@60Hz transmission 70 metres 4K@30Hz transmission 40 metres 1a Contact discharge level 2 (±4KV) 1b Air discharge level 3 (±8KV)
HDMI Performance and Interface - HDR HDMI Performance and Interface - HDR Support
Operating Environment - Storage temperature Operating Environment - Storage temperature -30°C~70°C
Operating Environment - Working temperature Operating Environment - Working temperature -20°C~60°C
HDMI Performance and Interface - EDID through HDMI Performance and Interface - EDID through Support
HDMI Performance and Interface - IR Pass-back HDMI Performance and Interface - IR Pass-back Frequency Range: 20KHz~60KHz
HDMI Performance and Interface - Audio formats HDMI Performance and Interface - Audio formats DTS, DTS-HD, PCM, LPCM
HDMI Performance and Interface - HDMI resolution HDMI Performance and Interface - HDMI resolution 800x600, 1024x768, 1280x720, 1280x960, 1366x768, 1440x900, 1680x1050, 1920x1080, 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@24/25/30/50/60Hz, 3840x2160@24/25/30Hz
Operating Environment - Humidity (no condensation) Operating Environment - Humidity (no condensation) 0%~90% RH
HDMI Performance and Interface - Input and output DDC signal HDMI Performance and Interface - Input and output DDC signal 5Vp-p (TTL)
HDMI Performance and Interface - Input and output TMDS signal HDMI Performance and Interface - Input and output TMDS signal 0.7~1.2Vp-p (TMDS)
Protection Level - Electrostatic protection of the whole machine Protection Level - Electrostatic protection of the whole machine Implementation of the standard: IEC61000-4-2
$129.94 inc GST
