LENOVO THINKSYSTEM ST50 V2 3.5" S4520 480GB READ INTENSIVE SATA 6GB NHS SSD
Servers & Storage > Servers
- Brand: LENOVO
- Category: Servers
- SKU: 4XB7A77455
- MPN: 4XB7A77455
LENOVO
Lenovo 4XB7A77455 internal solid state drive 480 GB 3.5" Serial ATA…
- Our SKU
- MPN
- Barcode
- Rating
- No reviews yet
−14%
Overview
The ThinkSystem S4520 Read Intensive SATA SSDs are advanced 6Gb SATA solid-state drives that use 144-layer Intel 3D NAND TLC Flash Memory technology to provide an affordable solution with industry leading performance.
This product guide provides essential presales information to understand the S4520 SSDs, their key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about S4520 SSDs and consider their use in IT solutions.
Key features
- Security algorithms: 256-bit AES
- SSD capacity: 480 GB
- SSD form factor: 3.5"
- Interface: Serial ATA III
- Memory type: 3D TLC NAND
- Component for: Server/workstation
- Random read (4KB): 79000 IOPS
- Random write (4KB): 30000 IOPS
- S.M.A.R.T. support: Yes
- Mean time between failures (MTBF): 2000000 h
- Certification: FCC Title 47, Part 15B, Class B EN-55035:2017 EN-55022:2006 EN-55032:2012 Low Voltage Directive (LVD) 2014/35/EU EMC Directive 2014/30/EU RoHS Directive 2011/65/EU WEEE Directive 2012/19/EU UL 60950-1, 2nd Edition, 2014-10-14 CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-010 UL/CSA 62368-1, 2nd Edition AS/NZ CISPR 32:2015 AS/NZ CISPR 22:2009 +A1:2010 Taiwan BSMI EMC standard CNS 13438 Korea KCC Article 11.1 Morocco Decree # 2574-14 (EMC) Canada ICES-003 Japan VCCI China EFUP
- Power consumption (max): 3 W
- Width: 257 mm
- Depth: 193 mm
- Height: 95 mm
- Weight: 484 g
- Operating temperature (T-T): 0 - 70 °C
- Storage temperature (T-T): -40 - 75 °C
- Operating relative humidity (H-H): 5 - 95%
- Operating shock: 1000 G
- Non-operating shock: 1000 G
- Maximum operating altitude: 3050 m
- Compatible products: ThinkSystem ST50 V2
Specifications
Power
| Power consumption (max) | 3 W |
|---|
Features
| Security algorithms | 256-bit AES |
|---|---|
| SSD capacity | 480 GB |
| SSD form factor | 3.5" |
| Interface | Serial ATA III |
| Memory type | 3D TLC NAND |
| Component for | Server/workstation |
| Random read (4KB) | 79000 IOPS |
| Random write (4KB) | 30000 IOPS |
| S.M.A.R.T. support | Yes |
| Mean time between failures (MTBF) | 2000000 h |
| Certification | FCC Title 47, Part 15B, Class B EN-55035:2017 EN-55022:2006 EN-55032:2012 Low Voltage Directive (LVD) 2014/35/EU EMC Directive 2014/30/EU RoHS Directive 2011/65/EU WEEE Directive 2012/19/EU UL 60950-1, 2nd Edition, 2014-10-14 CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-010 UL/CSA 62368-1, 2nd Edition AS/NZ CISPR 32:2015 AS/NZ CISPR 22:2009 +A1:2010 Taiwan BSMI EMC standard CNS 13438 Korea KCC Article 11.1 Morocco Decree # 2574-14 (EMC) Canada ICES-003 Japan VCCI China EFUP |
Other features
| Compatible products | ThinkSystem ST50 V2 |
|---|
Weight & dimensions
| Width | 257 mm |
|---|---|
| Depth | 193 mm |
| Height | 95 mm |
| Weight | 484 g |
Operational conditions
| Operating temperature (T-T) | 0 - 70 °C |
|---|---|
| Storage temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating shock | 1000 G |
| Non-operating shock | 1000 G |
| Maximum operating altitude | 3050 m |
