NETGEAR XSM4324CS-100AJS AV Line 24-Port 10GigE Managed Network Switch with SFP+

AV Line 24-Port 10GigE Managed Network Switch with SFP+

  • Brand: NETGEAR
  • Category: Switches
  • SKU: XSM4324CS-100AJS
  • MPN: XSM4324CS-100AJS
NETGEAR

NETGEAR M4300-24X Managed L3 10G Ethernet (100/1000/10000) Black

SKU
CNZ-SN-001795
MPN
XSM4324CS-100AJS
Warranty
60 months

Overview

NETGEAR ProSAFE M4300-24X Stackable L3 Managed Switch comes with 24-port 10GBASE-T, 4-port shared 10GBASE-X SFP+ and 480Gbps fabric in a half-width form factor. All 24 ports are 1G backward compatible for progressive transition to 10G speeds. M4300-24X is line-rate with 480Gbps fabric for spine and leaf stacking architectures. M4300 Switch Series delivers L2/L3/L4 and IPv4/IPv6 rich services for mid-enterprise edge and SMB core with unrivalled ease of use: 10 Gigabit models can seamlessly stack with 1 Gigabit models within the series. Non-stop forwarding (NSF) virtual chassis architectures provide advanced High Availability (HA) with hitless failover, that is, distributed link aggregation allows for load balancing and virtually zero downtime. M4300 is ideal for server aggregation with Auto-iSCSI prioritization: two half-width M4300 switches can be installed in a single rack space for redundant Top of Rack installations. Layer 3 feature set includes static and policy-based routing, RIP, VRRP, OSPF, and PIM dynamic routing – as standard. The NETGEAR M4300 Switch Series is also ready for the future, with Software-defined Network (SDN) and OpenFlow 1.3 enabled for your network.

Key features

  • Switch type: Managed
  • Switch layer: L3
  • Quality of Service (QoS) support: Yes
  • ARP inspection: Yes
  • System event log: Yes
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
  • SFP+ module slots quantity: 4
  • Console port: RJ-45
  • USB 2.0 ports quantity: 2
  • Networking standards: IEEE 802.1AX, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3u, IEEE 802.3z
  • 10G support: Yes
  • Port mirroring: Yes
  • Flow control support: Yes
  • Link aggregation: Yes
  • Broadcast storm control: Yes
  • Auto MDI/MDI-X: Yes
  • Spanning tree protocol: Yes
  • Auto-negotiation: Yes
  • VLAN support: Yes
  • Virtual LAN features: Private VLAN, Voice VLAN, Tagged VLAN
  • Number of VLANs: 4000
  • Switching capacity: 480 Gbit/s
  • Forwarding rate: 357 Mpps

Specifications

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)125 W

Design

Rack mountingYes
StackableYes
Product colourBlack
Housing materialMetal
Reset buttonYes

Network

Networking standardsIEEE 802.1AX, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3u, IEEE 802.3z
10G supportYes
Port mirroringYes
Flow control supportYes
Link aggregationYes
Broadcast storm controlYes
Auto MDI/MDI-XYes
Spanning tree protocolYes
Auto-negotiationYes
VLAN supportYes
Virtual LAN featuresPrivate VLAN, Voice VLAN, Tagged VLAN
Number of VLANs4000

Security

DHCP featuresDHCP server, DHCP relay, DHCP client

Performance

Internal memory1024 MB
Flash memory256 MB
Noise level37 dB
Mean time between failures (MTBF)247437 h

Certificates

CertificationVCCI Class A

Data transmission

Switching capacity480 Gbit/s
Forwarding rate357 Mpps
MAC address table16000 entries
Store-and-forwardYes
Latency (1 Gbps)1.827 µs
Latency (10 Gbps)2.728 µs
Jumbo frames supportYes
Jumbo frames9216
Packet buffer memory32 MB

Multicast features

Multicast supportYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports type10G Ethernet (100/1000/10000)
SFP+ module slots quantity4
Console portRJ-45
USB 2.0 ports quantity2

Management features

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
ARP inspectionYes
System event logYes

Weight & dimensions

Width212 mm
Depth345 mm
Height44 mm
Weight4.14 kg

Operational conditions

Operating temperature (T-T)0 - 50 °C

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Questions

$9,026.34inc GST
