Opengear ACM7008-2-LMP-GLB ACM7008-2-LMP 8 serial Cisco Straight pinout ext power 2 GbE APAC LTE cellular dual SIM 2 DIO and 2 output ports Global Power Supply

Our SKU
MPN
Barcode
Warranty: 60 months
Rating: No reviews yet

Opengear ACM7008-2-LMP-GLB ACM7008-2-LMP 8 serial Cisco Straight pinout ext power 2 GbE APAC LTE cellular dual SIM 2 DIO and 2 output ports Global Power Supply — Opengear

Overview

ACM7008-2-LMP 8 serial Cisco Straight pinout ext power 2 GbE APAC LTE cellular dual SIM 2 DIO and 2 output ports Global Power Supply

Specifications

Brand

Brand	Opengear

Vendor

Vendor	Opengear

Weight

Weight	600 g

Warranty

Warranty	4 years hardware and support

Vendor code

Vendor code	Opengear

Vendor site

Vendor site	Opengear

Product name

Product name	Opengear

Product type

Product type	Opengear

Display depth

Display depth	120 mm

Display width

Display width	120 mm

Input voltage

Input voltage	12 V DC, 120 V AC, 230 V AC

Product model

Product model	Opengear

What's in box

What's in box	ACM7000 Resilience Gateway 1 x C14 Power Cable External Rack Mount Tab Black Terminal Block 2 x Blade Antennas DB9F-RJ45 Adapter 4 x Rubber Feet 12v Global Power Supply Antenna Extension Kit

Display height

Display height	120 mm

Ethernet ports

Ethernet ports	2

Product family

Product family	Opengear

Product series

Product series	Opengear

Additional info

Console Ports: 8 x RJ45 RS-232 Cisco straight pinout console ports Ethernet Ports: 2 x 10/100/1000 Ethernet | All Ethernet/SFP Fiber port with 1500V AC Isolation and ESD Protection Serial Ports: Cisco straight 50 to 230,400 bps USB Ports: 4 x USB 2.0 Console Ports Remote Access: Integrated 4G LTE Cellular Card, Dual Ethernet, aggregation & redundancy, Automatic Network Failover, Easy browser UI, IPv6 I/O Ports: 2 x TTL level Digital I/O ports (DIO) 5V DC max @ 20mA (supports external water /smoke /motion dry contact sensors) 2 High Voltage Digital Outputs (HVDO) 5-30V DC@ 100mA (drives relays, alarms, etc. Power Consumption: Less than 11.5W Form Factor: Compact CPU: 800 MHz Armada 370 ARMv7 SoC (Marvell 88F6W11) Memory: 256 MB DDR3 SDRAM 32 MB Embedded NOR Flash Internal Storage: 4 GB NAND Flash Operating Temperature: -25°C to 60°C, -13°F to 140°F Storage Temperature -40°C to +75°C, -40°F to +167°F Humidity: 5% to 90% Cellular Modules: Sierra Wireless EM7565 Cat-12 600Mbps/150Mbps (Download/Upload) MTBF: 100,000 Hours (Power Supply) 8 serial Cisco Straight pinout, ext power, Dual 1 GbE Ethernet, 4G LTE cellular, dual SIM, 2 DIO and 2 output ports, Global Power Adapter

Compliance & standards

AT& T and Verizon Certified MIC-R and MIC-T Certified PTCRB GCF KDDI/docomol/Softbank/Telstra EN 55022:2010 CISPR 22:2008 FCC Part 15 Subpart B:2015 ICES-003 Issue 5 (2014) AS/NZS CISPR 22:2009+A1:2010 EN 61000-3-2:2006/A2:2009 EN 61000-3-3:2008 EN 55024:2010 CISPR 24:2010 EN 61000-4-2:2009 EN 61000-4-3:2006+A2:2010 EN 61000-4-4:2004+A1:2010 EN 61000-4-5:2006 EN 61000-4-6:2009 EN 61000-4-8:2010 En 61000-4-11:2004 CE UL 1950 TUV C-Tick Security features to support NERC CIP standards FIPS 140-2 validated module Certificate #2473 PSE Mark BIS Mark

Questions

$3,380.99inc GST
