StarTech.com Gigabit Ethernet MM Fiber Converter SC
Gigabit Ethernet Multi Mode Fiber Media Converter SC 550m - 1000 Mbps
- Brand: StarTech.com
- Category: Network Accessories
- SKU: 2061225
- MPN: ET91000SC2
StarTech.com
StarTech.com Gigabit Ethernet Multi Mode Fiber Media Converter SC…
- SKU
- CNZ-IM-021487
- MPN
- ET91000SC2
- Rating
- No reviews yet
Overview
Convert and extend a Gigabit Ethernet connection up to 550 m / 1804 ft over Multi Mode SC fiber
The ET91000SC2 1000 Mbps Gigabit Multimode Fiber Media Converter (SC, 550m) lets you extend a Gigabit Ethernet network over multimode fiber, at distances up to 550m (1804 ft).
A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-SX) fiber backbone, the GbE to MM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, this Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.
For added versatility, the fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Link loss forwarding, remote status monitoring help ensure maximum up-time
- Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility
- Rugged steel casing for durability in harsh environments
The ET91000SC2 1000 Mbps Gigabit Multimode Fiber Media Converter (SC, 550m) lets you extend a Gigabit Ethernet network over multimode fiber, at distances up to 550m (1804 ft).
A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-SX) fiber backbone, the GbE to MM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, this Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.
For added versatility, the fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Link loss forwarding, remote status monitoring help ensure maximum up-time
- Provides Ethernet to Fiber conversion as a standalone device, or can be installed into the ETCHS2U 20 slot chassis for added versatility
- Rugged steel casing for durability in harsh environments
Key features
- Maximum data transfer rate: 2000 Mbit/s
- Ethernet interface type: Gigabit Ethernet
- Auto MDI/MDI-X: Yes
- Duplex system: Full, Half
- Maximum transfer distance: 550 m
- Wavelength: 850 nm
- Wavelength-division multiplexing (WDM): No
- Fiber mode structure: Multi-mode
- Mean time between failures (MTBF): 65000 h
- Internal: No
- Product colour: Black
- Housing material: Steel
- Connectivity technology: Wired
- Ethernet LAN (RJ-45) ports: 1
- Fiber optic connector: SC
- Input voltage: 115 - 230 V
- Input current: 0.36 A
- Output voltage: 12 V
- Output current: 1.6 A
- Power consumption (typical): 4 W
- External power adapter: Yes
- Power plug type: Type M
- Width: 90 mm
- Depth: 150 mm
Specifications
Power
| Input voltage | 115 - 230 V |
|---|---|
| Input current | 0.36 A |
| Output voltage | 12 V |
| Output current | 1.6 A |
| Power consumption (typical) | 4 W |
| External power adapter | Yes |
| Power plug type | Type M |
Network
| Maximum data transfer rate | 2000 Mbit/s |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| Auto MDI/MDI-X | Yes |
| Duplex system | Full, Half |
Features
| Internal | No |
|---|---|
| Product colour | Black |
| Housing material | Steel |
Performance
| Maximum transfer distance | 550 m |
|---|---|
| Wavelength | 850 nm |
| Wavelength-division multiplexing (WDM) | No |
| Fiber mode structure | Multi-mode |
| Mean time between failures (MTBF) | 65000 h |
Certificates
| Compliance certificates | RoHS |
|---|---|
| Certification | CE, FCC |
Logistics data
| Harmonized System (HS) code | 85176990 |
|---|
Packaging data
| Package width | 205 mm |
|---|---|
| Package depth | 138 mm |
| Package height | 89 mm |
| Package weight | 766 g |
Packaging content
| AC adapter included | Yes |
|---|---|
| Manual | Yes |
Ports & interfaces
| Connectivity technology | Wired |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber optic connector | SC |
Weight & dimensions
| Width | 90 mm |
|---|---|
| Depth | 150 mm |
| Height | 25 mm |
| Weight | 562 g |
Operational conditions
| Operating temperature (T-T) | 0 - 60 °C |
|---|---|
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
